ASHATA LGA 1150 Mini ITX Gaming Motherboard, B85 Chipset with M.2 NVMe Suppo

• H81 LGA 1150 Motherboard: The LGA 1150 motherboard uses the H81 chipset. It support for 's 4th generation Core i3/i5/i7, support for E3/V3 series, support for Celeron G series, and support for Pentium G series 22nm CPU processors (for example, support for Core i7-4770 i5-4670 i5-4590 i3-4170, support for E3-1285 v3, support for Pentium G3470, support for Celeron G1830, etc.).
• Dual Channel DDR3 Memory Slots: The motherboard has 2 x 240 pin DDR3 SDRAM desktop memory slots. It supports dual channel with effective frequencies of DDR3 1066/1333/1600 MHz. The maximum single memory capacity is 8GB, and the total maximum capacity is 16GB.
• B85 Desktop Motherboard with M.2: This is an upgraded version of the B85 M.2 luxury motherboard. It features a high speed M.2 NVMe hard drive interface and an M.2 WiFi slot. It has fast PCIe hard drive switching and 3 x Serial ATA 3.0 (6GB/s) channels. It also has an onboard support for 10/100/1000Mbps network card and support for ALC662 hifi independent sound card.
• Durable Motherboard: The B85 gaming motherboard uses a durable 8 layer PCB material, an 8 phase power supply, and all solid state capacitors. It is finely made and highly stable. Additionally, the DDR3 motherboard has a 24+8 pin power connector, which is less likely to bend and ensures stable circuit operation, thus increasing the motherboard's lifespan.
• I/O Ports: The desktop motherboard offers various I/O ports, including 4 USB 2.0 ports, 2 USB 3.0 ports, 1 VGA port, 1 HD Multimedia Interface compatible port, 1 RJ45 port, and a 3 in 1 sound interface (line in/line out/microphone).

Specification:
Item Type: Gaming Motherboard
Model: B85
Product Material: PCB
Battery: CR2032 (Built in) Capacity: 220mAh
CPU: Socket support for i3 i5 CPU (LGA1150)
Memory: 2 x 240 pin DDR3 SDRAM slots; Maximum 16GB; Supports Dual Channel DDR3 1066/1333/1600 MHz
Storage Interface: 3 x Serial ATA 3.0 (6Gb/s) ports, 1 x M.2 NVMe slot
Integrated LAN: Onboard support for 10/100/1000Mbps LAN, 1 x M.2 WiFi slot
Expansion Slot: 1 x PCI Express x16 slot
Integrated Sound: Onboard support for ALC662 HiFi Sound
Power Interface: 1 x ATXPWR 24 pin interface, 1 x 8 pin ATX12V interface
I/O Ports: 4 x USB 2.0, 2 x USB 3.0, 1 x VGA, 1 x HD Multimedia Interface, 1 x RJ45, 1 x 3 in 1 Sound (Line in/Line out/Mic in)

How to Use:
Ready to use right out of the box

PackageList:
1 x Computer Motherboard
1 x Serial ATA Cable
1 x Baffle
