120A MPPT Solar Charge Controller,12V 24V 36V 48V 60V 72V 84V 96V Solar Battery Regulator PV Max 230V for Sealed Lead Acid Gel and Lithium Battery

• 【Technical parameters】 Y&H 120A solar charge controller can automatically detect system voltage.12V battery:PV max 1440W;24V battery:PV max 2880W;36V battery:PV max 4320W;48V battery:PV max 5760W;60V battery:PV max 7200W;72V battery:PV max 8640W;84V battery:PV max 10080W;96V battery:PV max 11520W;PV input voltage (VOC) up to 230V.
• 【Compatible with multiple battery types】The solar controller is compatible with 12V/24V/36V 48V/60V/72V/84V/96V lithium-ion and lead-acid batteries, including GEL, LiFePO4, Li-ion, user. Wide coverage of battery voltage, whether it is as low as 12V or as high as 96V battery type, can be perfectly adapted. Extremely versatile, it can realize multi-purpose use and fully meet the requirements of different stages and various scenarios.
• 【Advantages】 Y&H MPPT controller is equipped with full power input function to provide stable and sufficient power for the equipment, which has obvious advantages in high-power and complex power demand scenarios.
• 【Multi-protection】Solar voltage regulator has overcharge protection, overcurrent protection, overheating protection, short circuit protection.Lithium battery activation can effectively activate lithium batteries that may be in a low-activity state and restore them to a good working condition, thus extending the service life of lithium batteries.
• 【Application Scenarios】: Off-grid solar power systems for homes and farms, off-grid solar power systems for small workshops and factories, RVs, boats and off-grid solar power systems.

Descriptive:
SOGTICPS Controller is used in solar off-grid power generation systems to automatically regulate battery charging and discharging. It has an advanced tracking algorithm to obtain the maximum power of the solar module to charge the battery; at the same time, its Low Voltage Disconnect (LVD) function prevents the battery from over-discharging and causing damage.

The MPPT controller’s comprehensive self-test function and electronic protection function can avoid damage caused by installation errors and system failures.
Features:
1.Maximum power point tracking technology, can significantly improve the energy utilization of solar energy system, conversion efficiency of up to 97%.
2.Battery voltage available:12V/24V/36V 48V/60V/72V/84V/96V
3.Multiple battery type settings: Lead Acid,Gel,LifePo4,Li,User
4.PV Open Circuit Voltage: 0V-230V,Charging current (A) is adjustable.
5.Automatic compensation of charging voltage and current according to battery temperature to prolong battery life.
6.Wide range of high voltage: the same type of 60A controller can withstand up to 150V, while the 12V battery can withstand up to 45V, Y&H controller 12V battery system can withstand up to 230V, the advantage is obvious.
7.PV minimum input is calculated as about 1.5-2 times the battery voltage. (Example: 12V battery, minimum input voltage is 18V-24V voc)

SERVICE GUARANTEE: Y&H is the first to introduce 12-96V battery system, if you are not satisfied with the MPPT solar controller we received, you can email us at any time, we will reply and solve your problem in time, and try our best to provide better service for you.
