Trend H C 2-Piece Hinge Jig Skeleton in Case, Black

Trend H C 2-Piece Hinge Jig Skeleton in Case

RRP PRICE: £269.93
SALE PRICE: £156.00
YOU SAVE: £113.93

About this item

  • EFFICIENT AND FAST: Built-in guide bush offsets on each hinge block, along with the indexed back set discs, ensure superfast setup and maximum efficiency; An additional 12mm diameter long-reach cutter such as the Trend C019AX1/4TC is required
  • VERSATILE USES: Internal or external doors; Frames and linings with rebates or fitted stops up to 25mm thick; The indexing back set positions cover standard 20mm, 25mm and 30mm hinge leaf widths; Easily adjusted for other hinge leaves
  • PRECISION ACCURACY: Hinge positions are replicated with pinpoint precision on the door and frame from a single set up for increased productivity on site, or in the workshop for pre-hung door and frame work
  • CONVENIENT FOR ANY WORKPLACE: Supplied in a robust carrycase with a 16mm guide bush and securing bradawls, a light duty router such as the Trend T5 is ideal for making the cuts; Ideal for fire work
  • INCLUDED: H/JIG/C; 3 x Hinge sliding aperture block assemblies; 4 x Bradawls (short blade); 1 x 16mm guide bush; 1 x Carry case
SKU: B00HUWYYE4
Weight: 3.75 kg
Dimensions: 137.16 x 15.24 x 12.7 cm; 3.75 Kilograms
Model: H/JIG/C 2-Piece Hinge Jig Skeleton
Part: H/JIG/C
Colour: Black
Pack Quantity: 2
Batteries Required: No
Batteries Included: No
Manufacture: Trend
Colour: Black
Quantity: 2

From the manufacturer

logo
h_jig_c

Contractor Two Part Skeleton Hinge Jig

Made from aluminium extrusion for strength and light weight for easy transport. To recess hinges in wooden doors and frames. Clean and accurate recesses are achieved every time with minimal set-up time, both on-site and in joinery shops

  • Fully adjustable quick release aperture blocks
  • Adjustable edge guides with three preset hinge widths
  • Suitable for timber based doors and square butt hinges. No need for marking out in conventional way
  • Use with a light duty router with 1/4” collet and long reach router cutter 12mm dia. x 70mm overall length
  • Jig thickness allows it to be used on frames with a maximum 25mm thick fixed stop fitted
  • Can be used to fit new door in an old frame. Ideal for renovation work.

h/jig/c

This Product Includes:

  • 3 x Hinge sliding aperture block assemblies
  • 4 x Bradawls (short blade)
  • 1 x 16mm guide bush
  • 1 x Carry case

Light Duty Router

Application

Hinges

Quick Release

Light Duty Router

Use with a light duty router with 1/4” collet and long reach router cutter 12mm dia. x 70mm overall length.

Application

Can be used to fit new door in an old frame. Ideal for renovation work.

Hinges

Suitable for timber based doors and square butt hinges. No need for marking out in conventional way.

Quick Release

Fully adjustable quick release aperture blocks.
