Steinel Outdoor Wall Light L 22 Anthracite, Motion Sensor Light, 180° Motion Detector, 10 m Range, Stainless Steel Porch Light, max. 60 W, E27

Steinel Outdoor Wall Light L 22 Anthracite

RRP PRICE: £77.00
SALE PRICE: £74.00
YOU SAVE: £3.00

About this item

    This fits your .
  • by entering your model number.
  • The designer exterior wall light L 22 with its attractive stainless steel screen is made of impact-resistant polycarbonate
  • The Steinel LED motion sensor light with E27 socket is compatible with incandescent bulbs max. 60 watts and for energy-saving or LED bulbs with max. 20 watts
  • The passive infrared motion sensor has a detection angle of 180° and a range of up to 10 metres
  • Follow-up time and twilight function can be set via easily accessible and discreetly positioned rotary controls on the underside of the sensor
  • Thanks to its translucent chassis, the L 22 sensor lamp provides an inviting and uniform ambience. Ideal for house entrances, house fronts, on the balcony or on the terrace

Product description

Colour:Charcoal

Product Description

Superior appearance, proven technology.Whether in the entrance area, on the balcony, on
the garage exterior or on the terrace – the LED outdoor wall light L 22 scores highly. With a clear
design and reliable Steinel sensor technology, the surprisingly low-cost luminaire is equipped with
a rust-free stainless steel screen and spreads an inviting light thanks to its translucent chassis.

Practical:the sensor and sconce cover are made of impact-resistant polycarbonate. This reduces
the risk of damage either by natural extremities or kids play. Follow-up time and twilight function
can be adjusted by discreet knobs on the underside of the sensor. The E27 socket is for
conventional incandescent lamps with a maximum of 60 watts as well as for energy saving or LED
lamps with a maximum of 20 Watts.

Mains connection : 220-240 V, 50/60 Hz

Set contains:
Lamp w/ mounting material
Cover Panel

Box Contains

1 x outdoor light.
1 x mounting accessories.
1 x cover panel.

SKU: B075NRW9WX
Weight: 800 g
Dimensions: 28.6 x 8.5 x 16.2 cm; 800 Grams
Brand: STEiNEL
Model: 4007841035709
Part: 4007841035709
Colour: Charcoal
Pack Quantity: 1
Batteries Required: No
Batteries Included: No
Manufacture: Steinel
Colour: Charcoal
Quantity: 1

From the manufacturer

L 22 Außenleuchte

With momentum into a bright future

The inviting lighting solution

L 22

Steinel
Our company

Steinel develops and manufactures sensor lights in its own factories in Europe. Made in Europe is our winning formula – and has been for over 50 years. Our products are renowned around the world for their easy handling and their longevity. Convince yourself!

Exterior light L 22

Inviting appearance

Inviting appearance: whether at the entrance, next to the building or on the patio – the L 22 sensor-switched outdoor light scores with clean lines and reliable STEINEL sensor technology.

  • Stainless steel cover
  • Impact and weather resistant
  • Reliable 180° detection
  • Vertically swivelling sensor
  • Ambience lighting on the wall
  • Individual time and twilight settings
  • For E27 lamps up to max. 60 W (max. 20 W LEDs)

Intelligent technology

Infrared Pyrosensor

Thermal

Hightech material

reach, motions sensor, motion detector

The pyro sensor

This electric module reacts as soon as the infrared thermal radiation within the detection zone changes. This causes a voltage jump which is then converted into an electronic impulse, which switches the light on or off.

Human thermal radiation

Due to their body heat humans emit infrared radiation. Infrared sensor technology uses this radiation to detect movement and to react accordingly.

Hightech material

Apart from the UV-resistant plastic, which assures an attractive appearance even after years of use, Magnesium Composite is used for the LED cooling system. This material from the aviation and aerospace sector, is employed here in serial manufacturing for the first time.

Reach

The reach of infrared sensors depends on the direction of movement. With tangential movements (parallel to the sensor) the reach is about 10 m on average, which is shortened when moving directly towards the sensor (radial movement). To attain the maximum reach the optimal mounting height of 2 m should be given.

Easy assembly and installation

Anbringen

Anschließen

Einsetzen

Einstellen und Fertig

Installation

For mounting, simply drill 4 holes and screw the housing tight.

Mounting accessories are included in the scope of delivery.

Connection

As with any conventional luminaire, wire and insulate the protectiveconductor if necessary.

Attachment

Insert the desired E27 lamp and fit the cover.

Set and done

Make adjustments under the sensor, align the sensor and Done.

L 12 L 20 L 22 L 224 LED L 244 LED
Output max. 60 W / E27 max. 60 W / E27 max. 60 W / E27 7,5 W 7,5 W
Luminous flux 410 lm 500 lm
Material UV-resistant plastic with aluminium cover UV-resistant plastic with aluminium cover UV-resistant plastic with aluminium cover UV-resistant plastic with aluminium cover UV-resistant plastic with aluminium cover
Angle of detection 180° 180° 180° 180° 180°
Max. reach 10 m 10 m 10 m 10 m 10 m
Sensor pivoting range 90° 90° 90° 90° 90°
Response brightness 2-2000 lx 2-2000 lx 2-2000 lx 2-2000 lx 2-2000 lx
Time setting 8 sec. – 35 min. 8 sec. – 35 min. 8 sec. – 35 min. 8 sec. – 35 min. 8 sec. – 35 min.
Protection type IP44 IP44 IP44 IP44 IP44
Ambient light
